12 November 2014

Making Copies of Copies with Oracle RMAN

I recently had need to make a copy of an image copy in Oracle rman. Since it wasn't immediately obvious to me, I thought it was worth sharing once I had it sorted out. I was familiar with making a backup of a backup, but had never thought about making a copy of a copy.

First you need to create an image copy of your database or tablespace. For the sake of example, I'll make a copy of the FOO tablespace. The key is to assign a tag to it that you can use for later reference. I'll use the tag "DTSCOPYTEST":

backup as copy
    tablespace foo
    tag 'DTSCOPYTEST'
    format '+DG1';

So I have my image copy in the DG1 tablespace. Now say we want to make copy of that for some testing purpose and put it in a different diskgroup. For that, we need the "BACKUP AS COPY COPY" command, and we'll want to specify the copy we just took by using the tag that was used:

backup as copy
    copy of tablespace foo
    from tag 'DTSCOPYTEST'
    tag 'DTSCOPYTEST2'
    format '+DG2';

As you'd guess, RMAN makes a copy of the first copy, writing it to the specified format location.

As always, hope this helps!

04 November 2014

The Importance of Backups (A Cautionary Block Recovery Tale)

Just wanted to share a quick story with everyone. As I was in the airport waiting to fly to Oracle OpenWorld this year, I noticed a flurry of emails indicating that part of our storage infrastructure for our standby production database had failed. Long story short, my co-workers did a brilliant job of stabilizing things and keeping recovery working. However, we ended up with more than a few block corruptions.

Using the RMAN command "validate database", we could then see the list of corrupt blocks in the v$database_block_corruption view. All that was needed was to run "recover corruption list" in RMAN, which will dig into datafile copies and backups to do what it can to repair or replace the corrupt blocks and then recover the datafiles. Of course, nothing is ever that easy for us!

The storage we were writing our weekly backups to had been having problems and the latest weekly had failed. We ended up having to back 2 weeks into backups to get the datafile blocks and archivelogs to eventually complete the corruption recovery. I also immediately moved our backups to more reliable storage as well so that we're never in the situation of wondering whether or not we have the backups we need.

So, triple-check your backup plan, validate your backups and TEST RECOVERY SCENARIOS! You can't say your backups are valid until you use them to perform a restore/recovery, and you don't want to find out the hard way that you forgot something.

22 October 2014

ORA-16534 When Converting to/from Snapshot Standby with DataGuard Broker

We here at Seilerwerks Industries (not really) have been using snapshot standby databases to refresh an array of unit test databases from a common primary. During the business day, these would be converted to snapshot standby databases for testing, then overnight they are converted back to physical standby and recovered up to the master again.

However we ran into one problem the other week. I noticed that the test3 database was still in physical standby mode well into the business day. Trying to manually convert returned this error:

DGMGRL> convert database test3 to snapshot standby
Converting database "test3" to a Snapshot Standby database, please wait...
Error:
ORA-16534: switchover, failover or convert operation in progress
ORA-06512: at "SYS.DBMS_DRS", line 157
ORA-06512: at line 1

A quick search of MOS yielded bug 13716797 (ORA-16534 from the broker when setting apply-off), which simply suggested restarting the problem database when encountering that error. However doing so did not get me any further. That's when the I checked the Data Guard Broker configuration:

DGMGRL> show configuration;

Configuration - testdb

  Protection Mode: MaxPerformance
  Databases:
    test1 - Primary database
    test5 - Physical standby database
    test6 - Snapshot standby database
    test3 - Physical standby database
    test4 - Snapshot standby database

Fast-Start Failover: DISABLED

Configuration Status:
ORA-16610: command "CONVERT DATABASE test6" in progress
DGM-17017: unable to determine configuration status

Looks like I have two databases stuck in physical standby mode, test3 and also test6. And the configuration is specifically complaining about test6. So I restarted that database and, sure enough, I was then able to convert both back to snapshots:

DGMGRL> show configuration;

Configuration - testdb

  Protection Mode: MaxPerformance
  Databases:
    test1 - Primary database
    test5 - Snapshot standby database
    test6 - Snapshot standby database
    test3 - Snapshot standby database
    test4 - Snapshot standby database

Fast-Start Failover: DISABLED

Configuration Status:
SUCCESS

It was very interesting to me to see one member of the Data Guard configuration prevent me from performing an operation on a different member. Hopefully this helps one of you in the future.

01 October 2014

Advanced Queue Quickie: Errors and Privileges

File this one under the misleading-errors department. One of my developers was working with a new queue. He pinged me when he got this error trying to create a job that used the queue:

ERROR at line 1:
ORA-27373: unknown or illegal event source queue
ORA-06512: at "SYS.DBMS_ISCHED", line 124
ORA-06512: at "SYS.DBMS_SCHEDULER", line 314
ORA-06512: at line 2

The CREATE_JOB statement was:

BEGIN
DBMS_SCHEDULER.CREATE_JOB(
job_name => 'foo.bar_q_job',
job_type => 'PLSQL_BLOCK',
job_action => 'begin foo.bar_pkg.consume_bar_queue(); end;',
queue_spec => 'BAR.BAR_Q, FOO_BAR_AGENT',
enabled => true,
comments => 'This is a job to consume the bar.bar_q entries that affect foo.');
END;
/

After a few minutes of banging our heads, it became obvious that this was a permissions problem. The queue was owned by BAR, the job was being created as FOO. The ORA error message could/should have made this more obvious, in my opinion.

Anyway, the fix was simply to grant access to FOO:

DBMS_AQADM.GRANT_QUEUE_PRIVILEGE(
        privilege  => 'ALL',
        queue_name => 'bar.bar_q',
        grantee    => 'foo' );

Hope this saves some banged heads for others.

10 September 2014

NOFILENAMECHECK Parameter Causes DUPLICATE DATABASE To Ignore DB_CREATE_FILE_DEST?

Last week I was creating a new testing database from a backup of our demo database, both under Oracle 11.2.0.3. I grabbed one of my old scripts to handle the duplicate function, which looked similar to this:

connect auxiliary /;
run {

        duplicate database to testdb
                backup location '$BACKUPDIR'
                nofilenamecheck;

}

One important difference between the demo database and this new test database is that the original demo database lives on a filesystem and the new database was to go onto ASM on a different host. I had copied the syntax from the old script and kicked it off. I made sure that the db_create_file_dest was set to the ASM diskgroup. However the restore would fail as RMAN tried to write to the filesystem path used by the original demo database, which didn't exist on this host, instead of the ASM diskgroup.

21 August 2014

ORA-14048 When Adding Composite Partition

Fresh off the heels of my earlier composite partitioning post, I just ran into this confusing issue:

SQL> alter table p_objects
  2          add partition p201410
  3                  values less than (to_date('2014/11/01','yyyy/mm/dd'))
  4          (
  5                  subpartition p201410_spdts values ('DTS')
  6                  , subpartition p201410_spfoo values ('FOO')
  7                  , subpartition p201410_spbar values ('BAR')
  8                  , subpartition p201410_spsys values ('SYS')
  9                  , subpartition p201410_spsysaux values ('SYSAUX')
 10          )
 11  tablespace tbs1
 12  ;
tablespace tbs1
*
ERROR at line 11:
ORA-14048: a partition maintenance operation may not be combined with other
operations

The error doesn't quite make it easy to determine what the problem is. Turns out that the tablespace/storage clause of the ALTER TABLE ... ADD PARTITION has to come prior to the subpartitions definition. Simply moving that part of the statement a few rows up yields success:

SQL> alter table p_objects
  2          add partition p201410
  3                  values less than (to_date('2014/11/01','yyyy/mm/dd'))
  4          tablespace tbs1
  5          (
  6                  subpartition p201410_spdts values ('DTS')
  7                  , subpartition p201410_spfoo values ('FOO')
  8                  , subpartition p201410_spbar values ('BAR')
  9                  , subpartition p201410_spsys values ('SYS')
 10                  , subpartition p201410_spsysaux values ('SYSAUX')
 11          )
 12  ;

Table altered.

Again, probably obvious to most of you. It wasn't as obvious to decipher when I was trying to add a partition with over 6,300 subpartitions. As always:


Adding New Partitions with Custom Subpartition Definition (Range-List)

As part of a project for work I wanted to create a script that would create a new range partition but also pre-create all the list subpartitions. By default the subpartitions would be created based on the subpartition template. However for various reasons which I won't get into we don't update or use the subpartition template. I wanted to define the subpartition list as part of the ALTER TABLE ... ADD PARTITION statement. I assumed it was perfectly acceptable but didn't see any obvious examples in my hasty web searching, so I thought I'd share on myself.

I start by creating my composite range-list partitioned table:

SQL> create table p_objects
  2  tablespace tbs1
  3  partition by range(rdate)
  4  subpartition by list(owner)
  5  subpartition template
  6  (
  7          subpartition spsys values ('SYS')
  8          , subpartition spsysaux values ('SYSAUX')
  9  )
 10  (
 11          partition p201301 values less than (to_date('2013/02/01','YYYY/MM/DD')),
 12          partition p201302 values less than (to_date('2013/03/01','YYYY/MM/DD')),
 13          partition p201303 values less than (to_date('2013/04/01','YYYY/MM/DD')),
 14          partition p201304 values less than (to_date('2013/05/01','YYYY/MM/DD')),
 15          partition p201305 values less than (to_date('2013/06/01','YYYY/MM/DD')),
 16          partition p201306 values less than (to_date('2013/07/01','YYYY/MM/DD')),
 17          partition p201307 values less than (to_date('2013/08/01','YYYY/MM/DD')),
 18          partition p201308 values less than (to_date('2013/09/01','YYYY/MM/DD')),
 19          partition p201309 values less than (to_date('2013/10/01','YYYY/MM/DD')),
 20          partition p201310 values less than (to_date('2013/11/01','YYYY/MM/DD')),
 21          partition p201311 values less than (to_date('2013/12/01','YYYY/MM/DD')),
 22          partition p201312 values less than (to_date('2014/01/01','YYYY/MM/DD'))
 23  )
 24  as select object_id
 25          , owner
 26          , object_name
 27          , object_type
 28          , to_date(trunc(dbms_random.value(
 29                  to_char(to_date('2013/01/01','YYYY/MM/DD'),'J'),
 30                  to_char(to_date('2013/12/31','YYYY/MM/DD'),'J')
 31                  )),'J') rdate
 32  from all_objects
 33  where owner in ('SYS','SYSAUX');

Table created.

This creates the partitions with 2 subpartitions each, per my defined template. For example:

PARTITION_NAME                 SUBPARTITION_NAME
------------------------------ ------------------------------
P201301                        P201301_SPSYS
                               P201301_SPSYSAUX
P201302                        P201302_SPSYS
                               P201302_SPSYSAUX
P201303                        P201303_SPSYS
                               P201303_SPSYSAUX

Next I'll add two more partitions, one with no subpartition definition specified and another with a custom definition:

SQL> alter table p_objects
  2          add partition p201408
  3                  values less than (to_date('2014/09/01','yyyy/mm/dd'));

Table altered.

SQL> alter table p_objects
  2          add partition p201409
  3                  values less than (to_date('2014/10/01','yyyy/mm/dd'))
  4          (
  5                  subpartition p201409_spdts values ('DTS')
  6                  , subpartition p201409_spsys values ('SYS')
  7                  , subpartition p201409_spsysaux values ('SYSAUX')
  8          )
  9  ;

Table altered.

The results:
PARTITION_NAME                 SUBPARTITION_NAME
------------------------------ ------------------------------
P201408                        P201408_SPSYS
                               P201408_SPSYSAUX
P201409                        P201409_SPDTS
                               P201409_SPSYS
                               P201409_SPSYSAUX

You can see that the first statement just used the subpartition template as defined in the original CREATE TABLE statement. The second uses the list I defined in the ALTER TABLE statement. I could have only defined the SPDTS subpartition and it would have only used that one and not used SYS or SYSAUX subpartitions at all.

Hopefully this post helps a few of you in your searching when faced with a similar task. This was probably obvious to most of you but the mind starts to slip for some of us.
